USED Dr. Z Z-Lux 112 1x12" 20/40-watt Tube Combo Amp

Free Shipping on Most Products

Free Shipping on Most order(s) above $14.99 (over-sized products not included)

Dr. Z Z-Lux 112 1x12" 20/40-watt Tube Combo Amp

“The point is that no matter how I fiddled with the tone controls, I couldn’t get a truly bad sound out of the Z-Lux. And there’s lots of leeway for getting a great one.” – Premier Guitar

Dr. Z has always said that his next design will be the best. Well, his next design is here. We are proud to add the Z-LUX to our line. The Z-LUX delivers that big, warm vintage tone of a true hand-wired tube amp. It’s a design that not only integrates favorite features from our entire line but also includes new ones of its own. Half/Full power switch, foot-switchable boost, master volume, reverb, tremolo, you name it…this amp has it. Every component was painstakingly selected to achieve the highest quality standards for both sound and durability.

The Z-LUX starts with the front end of the MAZ design and uses a combination of hand-rolled Jupiter caps, Mallory 150s, and classic Orange Drop caps specifically selected for each stage of the preamp. We also included the foot-switchable EQ bypass boost but softened it a bit for a smoother overdrive. The power section is driven by 6V6 power tubes, switchable between 2 tubes (20 watts) or 4 tubes (40 watts) via the half-power switch. The tube driven tremolo will give you deep pulsating swells of rich tone you can’t get from an effects pedal and when combined with the lush, tube driven spring reverb… you won’t be able to put the guitar down. The sound of this amp will push your creativity to the max!

We completely re-designed the build and makeup of our cabinets for this amp and were able to achieve stunning full-bodied sounds in a sturdy yet ultra-light combo cab weighing in at a back-saving 42 lbs! We also teamed up with Eminence to design a new 12” speaker. The new Z-12 is an American-voiced 50 watt speaker designed to complement the vibrant tones of the Z-LUX. Designing a cab and a speaker at the same time allowed us to have complete control over the quality of every component, truly achieving vintage tone for today.


  • Excellent tone from excellent, top-tier components
  • Eminence American-voiced speaker 12"
  • The half/full power switch reduces the amp's output from a stage-ready 40 watts to a studio-friendly 20 watts
  • 20 Separate preamp gain control makes dialing in your chosen degree of grit simple 3-band EQ for perfecting your tone
  • Deep, throbbing swells are produced by tube-driven tremolo
  • Spring reverb with a lush, tube-driven sound
  • Footswitchable boost to put your solos into overdrive


  • Type:Tube
  • Number of Channels:Single
  • Total Power:40W (20W half-power setting)
  • Speaker Size:1 x 12" Custom Eminence Z12
  • Preamp Tubes:4 x 12AX7, 1 x NOS 6201
  • Power Tubes:4 x 6V6
  • Reverb:Tube-driven, Spring Reverb
  • Effects:Tremolo
  • EQ:3-band EQ
  • Inputs:1 x 1/4" (instrument)
  • Outputs:3 x 1/4" (4/8/16 ohms, 8 ohm internal)
  • Footswitch I/O:1 x 1/4" (boost), 2 x RCA (Reverb, Tremolo)
  • Footswitch Included:Yes, 1-button (boost), 2-button (effects on/off)
  • Features:Cathode biased
  • Construction Material:Italian Poplar with Black Tolex
  • Power Source:Standard IEC AC cable
  • Height:19.25"
  • Width:22.5"
  • Depth:10.5"
  • Weight:42 lbs.
  • Manufacturer Part Number:ZA38112

Condition:Excellent. Light wear typical of a gently used Amp. Light surface scratches, scuffs, etc.
