Yamaha PSRSX900 61-key Arranger Workstation

The PSR-SX900 is the flagship in the PSR-SX Series. Surpassed only by the Genos, this power-house songwriting and performance keyboard features never before seen speaker technology, pro-level connectivity, and a completely redesigned user interface.

With a completely redesigned sound system, user interface, new assignable functions, Joystick and Live Controllers, you can completely tailor the functions and sounds of PSR-SX900, making your creativity positively limitless.

Perfect for songwriting, the PSR-SX900 is packed with rhythmic patterns (called "Styles") spanning many genres, making it ideal for creating the accompaniment to your musical ideas and an invaluable inspiration for your next composition or arrangement. Together with a tremendous range of expressive sounds and vocal harmony, the PSR-SX900 is your ultimate and inspirational musical partner.

		PSR-SX900	PSR-SX700	PSR-SX600
Color/Finish
Body	Color	Black	Black	BPalen Musiclack
Size/Weight
Dimensions	Width	1017 mm (40")	1017 mm (40")	1004 mm
	Height	139 mm (5.5")	139 mm (5.5")	134 mm
	Depth	431 mm (17")	431 mm (17")	410 mm
Weight	Weight	11.5 kg (25.35 lb)	11.5 kg (25.35 lb)	8.1 kg
Control Interface
Keyboard	Number of Keys	61	61	61
	Type	Organ (FSB), Initial Touch	Organ (FSB), Initial Touch	Organ, Initial Touch
	Touch Response	Normal, Soft 1, Soft 2, Hard 1, Hard 2	Normal, Soft 1, Soft 2, Hard 1, Hard 2	Normal, Soft 1, Soft 2, Hard 1, Hard 2
Other Controllers	Joystick	Yes	Yes	-
	Control Knobs	2 (assignable)	2 (assignable)	2 (assignable)
	Pitch Bend	-	-	Yes
	Modulation	-	-	Yes
Display	Type	TFT Color Wide VGA LCD	TFT Color Wide VGA LCD	TFT Color WQVGA LCD
	Size	800 x 480 dots (7 inch)	800 x 480 dots (7 inch)	480 x 272 dots (4.3 inch)
	Touch Screen	Yes	Yes	-
	Color	Color	Color	Color
	Language	English, German, French, Spanish, Italian	English, German, French, Spanish, Italian	English, German, French, Spanish, Italian, Japanese
Panel	Language	English	English	English
Voices
Tone Generation	Tone Generating Technology	AWM Stereo Sampling	AWM Stereo Sampling	AWM Stereo Sampling
Polyphony	Number of Polyphony (Max.)	128	128	128
Preset	Number of Voices	1337 Voices + 56 Drum/SFX Kits	986 Voices + 41 Drum/SFX Kits	850 Voices + 43 Drum/SFX Kits + 480 XG Voices
Preset	Featured Voices	252 S.Art!, 54 Mega Voices, 31 Sweet! Voices, 87 Cool! Voices, 131 Live! Voices, 24 Organ Flutes!	131 S.Art!, 30 Mega Voice, 31 Sweet! Voices, 74 Cool! Voices, 89 Live! Voices, 24 Organ Flutes!	73 S.Articulation!, 27 MegaVoice, 27 Sweet!, 64 Cool!, 71 Live!
Compatibility	XG	Yes (for Song playback)	Yes (for Song playback)	Yes (for Song playback)
	GS	Yes (for Song playback)	Yes (for Song playback)	Yes (for Song playback)
	GM	Yes	Yes	Yes
	GM2	Yes	Yes	Yes
Expandability	Expansion Voice	Yes (approx. 1 GB)	Yes (approx. 400 MB)	Yes (approx. 100MB max.)
Expandability	Editing	Voice Set	Voice Set	Voice Set
Part		Right 1, Right 2, Right 3, Left	Right 1, Right 2, Right 3, Left	Right 1, Right 2, Left
Effects
Types	Reverb	59 Presets + 30 User	59 Presets + 30 User	52 Preset + 30 User
	Chorus	106 Presets + 30 User	106 Presets + 30 User	106 Preset + 30 User
	DSP	322 Presets (with VCM) + 30 User	322 Presets + 30 User	295 Preset + 30 User
	Insertion Effect	1-8: 322 Presets (with VCM) + 30 User	1-5: 322 Presets + 30 User	-
	Master Compressor	5 Presets + 30 User	5 Presets + 30 User	5 Preset + 30 User
	Master EQ	5 Presets + 30 User	5 Presets + 30 User	5 Preset + 30 User
	Part EQ	28 Parts	28 Parts	27 Parts
	Others	Mic/Guitar Effects: Noise Gate, Compressor, 3 Band EQ, Vocal Effect: 23	Mic/Guitar effects: Noise Gate x 1, Compressor x 1, 3Band EQ x 1	Mic effects: Noise Gate x 1, Compressor x 1, 3 Band EQ
	Arpeggio	Yes	Yes	Yes
Vocal Harmony	Number of Presets	Vocal Harmony: 54, Synth Vocoder: 20	-	-
Vocal Harmony	Number of User Settings	60 *The number is the total of Vocal Harmony and Synth Vocoder	-	-
Accompaniment Styles
Preset	Number of Preset Styles	525	400	415
	Featured Styles	463 Pro Styles, 46 Session Styles, 10 DJ Styles, 6 Free Play	353 Pro Styles, 34 Session Styles, 10 DJ Styles, 3 Free Play	372 Pro Styles, 32 Session Styles, 10 DJ Styles, 1 Free Play
	Fingering	Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard	Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard	Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard, Smart Chord
	Style Control	INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3	INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3	INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3
Other Features	One Touch Setting (OTS)	4 for each Style	4 for each Style	4 for each Style
	Chord Looper	Yes	-	-
	Style Section Reset	Yes	Yes	Yes
	Unison & Accent	-	-	Yes
Expandability	Expansion Style	Yes (Internal Memory)	Yes (Internal Memory)	Yes (Internal Memory)
Expandability	Expansion Audio Style	Yes (Internal Memory)	-	-
Compatibility		Style File Format, Style File Format GE	Style File Format, Style File Format GE	Style File Format (SFF), Style File Format GE (SFF GE)
Songs
Preset	Number of Preset Songs	5 Sample Songs	5 Sample Songs	3 Sample Songs
Recording	Number of Songs	Unlimited (depends on the drive capacity)	Unlimited (depends on the drive capacity)	-
	Number of Tracks	16	16	16
	Data Capacity	Approx. 3 MB/Song	Approx. 3 MB/Song	Approx. 1 MB/Song
	Recording Function	Quick Recording, Multi Recording, Step Recording	Quick Recording, Multi Recording, Step Recording	Quick Recording, Multi Track Recording
Compatible Data Format	Playback	SMF (Format 0 & 1), XF	SMF (Format 0 & 1), XF	SMF (Format 0 & 1), XF
Compatible Data Format	Recording	SMF (Format 0)	SMF (Format 0)	SMF (Format 0)
Multi Pads
Preset	Number of Multi Pad Banks	329 Banks x 4 Pads	226 Banks x 4 Pads	188 Banks x 4 Pads
Audio	Audio Link	Yes	Yes	Yes
Functions
Registration	Number of Buttons	8	8	8
Registration	Control	Registration Sequence, Freeze	Registration Sequence, Freeze	Registration Sequence, Freeze
Playlist	Number of Records	2500 (max.) Records per Playlist file	2500 (max.) Records per Playlist file	500 (max.) Records per Playlist file
Lesson/Guide	Lesson/Guide	Follow Lights, Any Key, Karao-Key, Your Tempo	Follow Lights, Any Key, Karao-Key, Your Tempo	Follow Lights, Any Key, Karao-Key, Your Tempo
Search		Registration Bank	Registration Bank	Registration Bank
Demo/Help	Demonstration	Yes	Yes	Yes
Overall Controls	Metronome	Yes	Yes	Yes
	Tempo Range	5 - 500, Tap Tempo	5 - 500, Tap Tempo	5 - 500, Tap Tempo
	Transpose	-12 – 0 – +12	-12 – 0 – +12	-12 – 0 – +12
	Tuning	414.8 – 440 – 466.8 Hz	414.8 – 440 – 466.8 Hz	414.8 – 440.0 – 466.8 Hz
	Octave Button	Yes	Yes	Yes
	Scale Type	9 types	9 types	9 types
	Sub Scale Setting	Yes	-	-
Bluetooth		Yes (Audio) * May not have this functionality depending on the country	-	-
Miscellaneous	Direct Access	Yes	Yes	Yes
	Text Display Function	Yes	Yes	Yes
	Wallpaper Customization	Yes	Yes	-
	Display Out	Yes (by using a commercially available USB display adaptor) * For a list of compatible devices, access the “Yamaha Downloads” website.	Yes (by using a commercially available USB display adaptor) * For a list of compatible devices, access the “Yamaha Downloads” website.	-
Voices	Harmony/Echo	Yes (with Arpeggio)	Yes (with Arpeggio)	Yes (with Arpeggio)
	Panel Sustain	Yes	Yes	Yes
	Mono/Poly	Yes	Yes	Yes
	Voice Information	-	Yes	Yes
Styles	Style Creator	Yes	Yes	Yes
Styles	OTS Information	Yes	Yes	Yes
Songs	Score Display Function	Yes	Yes	Yes
	Lyrics Display Function	Yes	Yes	Yes
	Song Creator	-	Yes	Yes
Multi Pads	Multi Pad Creator	Yes	Yes	Yes
Audio Recorder/Player	Recording Time (max.)	80 minutes/Song	80 minutes/Song	80 minutes/Song
	Recording	.wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo), .mp3 (44.1 kHz sample rate,128/256/320 kbps, mono/stereo)	.wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo), .mp3 (44.1 kHz sample rate,128/256/320 kbps, mono/stereo)	*only on USB .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo)
	Playback	.wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo), .mp3 (MPEG-1 Audio Layer-3: 44.1/48.0 kHz sample rate, 64-320 kbps and variable bit rate, mono/stereo)	.wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo), .mp3 (MPEG-1 Audio Layer-3: 44.1/48.0 kHz sample rate, 64-320 kbps and variable bit rate, mono/stereo)	*only on USB .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo)
	Lyrics Display Function	Yes (.mp3 only)	Yes (.mp3 only)	-
	Time Stretch	Yes	Yes	Yes
	Pitch Shift	Yes	Yes	Yes
	Vocal Cancel	Yes	Yes	Yes
Storage and Connectivity
Storage	Internal Memory	Yes (approx. 4 GB)	Yes (approx. 1 GB)	Yes (approx. 20 MB max.)
Storage	External Drives	USB Flash Memory (via USB to DEVICE)	USB Flash Memory (via USB to DEVICE)	USB flash drive
Connectivity	Headphones	Yes	Yes	Yes
	FOOT PEDAL	1 (SUSTAIN), 2 (ARTICULATION), Function Assignable	1 (SUSTAIN), 2 (ARTICULATION), Function Assignable	1 (Sustain), 2 (Unison), Function Assignable
	Microphone	Microphone/Guitar x 1	Microphone/Guitar x 1	Microphone x 1
	MIDI	IN, OUT	IN, OUT	-
	AUX IN	Stereo mini jack	Stereo mini jack	Stereo mini jack
	LINE OUT	MAIN OUTPUT (L/L+R, R), SUB (AUX) OUTPUT (1,2 (L/L+R, R))	MAIN OUTPUT (L/L+R, R)	MAIN OUTPUT(L/L+R, R)
	USB TO DEVICE	Yes (x 2)	Yes	Yes
	USB TO HOST	Yes	Yes	Yes
Amplifiers and Speakers
Amplifiers		(15 W + 10 W) x 2	15 W x 2	15 W x 2
Speakers		13 cm x 2 + 2.5 cm (dome) x 2	13 cm x 2 + 5 cm x 2	12 cm x 2
Power Supply
Power Supply		PA-300C or an equivalent recommended by Yamaha	PA-300C or an equivalent recommended by Yamaha	PA-300C or an equivalent recommended by Yamaha
Power Consumption		24 W	21 W	17 W
Auto Power Off Function		Yes	Yes	Yes
Accessories
Included Accessories		Owner's Manual, Online Member Product Registration, Music Rest, AC Adaptor(may not be include depending on your area. Check with your Yamaha dealer.)	Owner's Manual, Online Member Product Registration, Music Rest, AC Adaptor(may not be include depending on your area. Check with your Yamaha dealer.)	Owner's Manual, Online Member Product Registration, Music Rest, AC Adaptor (may not be include depending on your area. Check with your Yamaha dealer.)
