Behringer WING 48-Channel Digital Mixer - Black

Channels: 48 Stereo (40 FlexChannels, 8 Aux)

Buses: 28 Stereo (4 Main, 8 Matrix, 16 Aux)

Inputs - Mic Preamps: 8 x XLR (Midas PRO)

Outputs - Main: 8 x XLR (Midas PRO)

Faders: 24 x 100mm Motorized (divided into 3 configurable sections)

Display: 10.1" TFT LCD capacitive multi-touch screen (adjustable swivel 15° to 60°)

Effects Engines: 16 True-stereo engines with 80+ algorithms

Local I/O Connectivity: 3 x AES50 ports (up to 144 inputs/outputs on SuperMac CAT5), StageConnect Host interface (32 channels), 1 x AES/EBU out, MIDI I/O, 4-channel GPIO

Computer Connectivity: Integrated USB Audio/MIDI Interface (48 channels in/out)

Onboard Recording: Dual-SD card live recorder/player (up to 64 tracks simultaneously)

Expansion Slot: 1 x Rear panel slot supporting optional 64-channel cards (Dante, WSG, MADI)

Frequency Response: 10 Hz - 20 kHz (@ 48 kHz sample rate)

A/D Dynamic Range: 112 dB (XLR preamplifier and converter typical)

D/A Dynamic Range: 118 dB (Converter and XLR output typical)

Power Supply: Auto-ranging 100-240 VAC (50/60 Hz), 130 W consumption

Dimensions (HxWxD): 7.9" x 34.3" x 22.6" (201 x 870 x 575 mm)

Weight: 52.8 lbs. (24 kg)

48 FlexChannels & 28 Buses: Effortlessly configure mono, stereo, or M/S formats across all 48 input channels and 28 buses with no performance cost.

Premium Midas PRO Sonic Performance: Features 8 world-class Midas PRO microphone preamplifiers and 8 Midas PRO outputs for unmatched clarity and dynamic range.

Tactile & Responsive Surface: Experience intuitive workflow control using 24 motorized 100 mm faders divided into three fully independent, configurable sections.

Vivid 10.1" Multi-Touch Display: Features an adjustable swivel touch-screen interface along with a touch-sensitive channel editing section for rapid adjustments.

Elite Onboard Studio Effects: Packed with 16 true-stereo effects processing engines and over 80 world-class algorithms modeled after iconic vintage hardware.
