Earthquaker Devices Sea Machine Chorus v2

The Sea Machine is a chorus pedal with ultimate control over parameters rarely seen in a chorus. A hybrid of digital and analog circuitry with a slightly extended delay time allows it to really stand out and shimmer. The heart of the Sea Machine is a short digital delay line, which features controls for Animation, Dimension and Depth.

Designed with and for Dirt Pedals

The Sea Machine also was designed to work well following fuzz, distortion or overdrive without getting muddy, reducing volume or breaking up. When engaged, the transparent buffer leaves the all-analog dry signal unaltered and crystal clear. The Sea Machine is true bypass and made by human hands with the highest quality parts in shimmering Akron, Ohio.

Highlights

• Rate: Sets the speed of the LFO. The miniature LED will show the tempo even in bypass mode.
• Shape: From soft triangle through hard square wave.
• Dimension: Adds a slight slap-back at low levels, reverb-like ambiance at mid levels and an echo-resonance at max.
• Intensity: How much the LFO modulates the delay time.
• Animate: ow far the pitch shifted signal swings, lower levels equals a tighter and more focused shift ÌÊ la traditional chorus. As you increase the control a more wild and animated pitch shift begins to emerge.
• Depth: How much modulated signal is blended in with the dry signal.

Specifications

• Pedal Type: Chorus
• Inputs: 1 x 1/4" instrument
• Outputs: 1 x 1/4" instrument
• Power: 9v DC power supply not included
• Draw: 50mA
• Length: 4.625"
• Width: 2.5"
• Height: 2.25"
• Manufacturer Part Number: SMC2
