Yamaha TF1

Item ID: TF1


Yamaha TF1

Item ID: TF1

Retail Price

PMC Savings

FREE Shipping


FREE Tech Support


16-Input Digital Mixer with 40 Mixing Channels, 20 Aux Busses, 17 Motorized Faders, and 1 Knob Compression/EQ


Yamaha TF1 Digital Mixing Console Features:

  • 17 motor faders (16 channels + 1 master)
  • 40 input mixing channels (32 mono + 2 stereo + 2 return)
  • 20 Aux buses (8 mono + 6 stereo) + Stereo + Sub
  • 8 DCA groups with Roll-out
  • 16 analog XLR/TRS combo mic/line inputs + 2 analog RCA pin stereo line inputs
  • 16 analog XLR outputs
  • 34 x 34 digital record/playback channels via USB 2.0 + 2 x 2 via a USB storage device
  • 1 expansion slot for NY64-D audio interface card


Yamaha's Corporate Philosophy

With our unique expertise and sensibilities, gained from our devotion to sound and music, we are committed to creating excitement and cultural inspiration together with people around the world.


Product Specifications:


Type: Digital
Channels: 16 (Expandable to 40 Input Mixing Channels)
Inputs - Mic Preamps: 16 x XLR - 1/4" Combo
Inputs - Other: 2 x Stereo (RCA), 1 x 1/4" (Footswitch)
Outputs - Main: 16 x XLR
Busses/Groups: 20 x Aux, 1 x Stereo, 1 x Sub
Data I/O: Ethernet
USB: 2 x USB Type A, 1 x USB Type B
Computer Connectivity: USB (34 x 34 Playback/Recording)
I/O Expansion Slots: NY64-D Audio Interface Card
Headphones: 1 x 1/4"
EQ Bands: 4-Band EQ
Faders: 17 x 100mm Throw
Effects: 8 Effects
Computer Connectivity: USB (34 x 34 Playback/Recording)
Rackmountable: Yes
Height: 8.9"
Width: 20.1"
Depth: 23.6"
Weight: 29.8 lbs.
Manufacturer Part Number: TF1
