The YDP-165 features a piano Voice sampled from Yamaha’s flagship CFX concert grand piano—a renowned piano that delivers sparkling highs and a powerful resonant bass combined in a superbly expressive sound.
The YDP-165 has the same detailed sound—from the lower keys to the higher keys—full of clarity and rich in colorful harmonic content. It gives you extraordinary expressive power and nuance, that authentically responds in your daily practice as well as your most emotion-filled performances.
With an 88-key piano action, the GH3 (Graded Hammer 3) keyboard reproduces the touch of an acoustic piano, from a naturally heavy feel in the lower key to a lighter touch in the upper octaves. The GH3 keyboard provides a grand piano-style response and feel, allowing rapid note repetition and authentic expressive control. Moreover, there’s a half-damper feature that authentically replicates the damper action on a grand piano, providing rich expressive variation.
One of the allures of the grand piano is the sympathetic resonance created by the vibration of the entire instrument. The YDP-165 elaborately reproduces this rich sympathetic resonance through a groundbreaking technology called Virtual Resonance Modeling Lite (VRM Lite). VRM Lite creates a richly varied sound by simulating the complex sympathetic tones created when the vibrations of the strings are propagated to the soundboard and other strings, corresponding to the timing and intensity of key playing and pedaling.
|
|
|
||
|---|---|---|---|
| Dimensions | Width | 1,357 mm [53-7/16"] | 1,353 mm [53-1/4"] |
| Height | 849 mm [33-27/64"] (With music rest raised: 1,003 mm [39-31/64"]) | 792 mm [31-3/16"] (Key cover open: 968 mm [38-1/8"] | |
| Depth | 422 mm [16-5/8"] | 296 mm [11-5/8"] (Key cover open: 309 mm [12-3/16"]) *With anti-fall brackets attached, the depth is 366 mm [14-13/32"]. | |
| Weight | Weight | 42.0 kg (92 lbs., 10 oz.) | 37.0 kg (81 lbs.,9 oz.) |
| Packing Box | Width | 1,449 mm [57-3/64"] | 1,463 mm [57-19/32"] |
| Height | 479 mm [18-55/64"] | 524 mm [20-5/8"] | |
| Depth | 584 mm [22-63/64"] | 424 mm [16-11/16"] | |
| Keyboard | Number of Keys | 88 | 88 |
| Type | GH3 keyboard with synthetic ebony and ivory keytops | GHS keyboard with matte black keytops | |
| Touch Sensitivity | - | - | |
| Touch Response | Hard/Medium/Soft/Fixed | Hard/Medium/Soft/Fixed | |
| Pedal | Number of Pedals | 3: Damper (with half-pedal function), Sostenuto, Soft | 3: Damper (with half-pedal function), Sostenuto, Soft |
| Half Pedal | Yes | Yes | |
| Functions | Damper, Sostenuto, Soft | Damper, Sostenuto, Soft | |
| Display | Type | - | - |
| Size | - | - | |
| Language | - | - | |
| Panel | Language | English | English |
| Key Cover | Key Cover Style | Sliding | Folding |
| Music Rest | Yes | Yes | |
| Music Clips | Yes | - | |
| Tone Generation | Piano Sound | Yamaha CFX | Yamaha CFX |
| Key-off Samples | Yes | Yes | |
| Smooth Release | Yes | - | |
| Virtual Resonance Modeling (VRM) | - | - | |
| String Resonance | - | - | |
| Damper Resonance | - | - | |
| Virtual Resonance Modeling Lite (VRM Lite) | Yes | Yes | |
| Polyphony | Number of Polyphony (Max.) | 192 | 192 |
| Preset | Number of Voices | 10 | 10 |
| Compatibility | - | - | |
| Types | Reverb | 4 | 4 |
| Chorus | - | - | |
| Brilliance | - | - | |
| Master Effect | - | - | |
| Intelligent Acoustic Control (IAC) | Yes | Yes | |
| Stereophonic Optimizer | Yes | Yes | |
| Functions | Dual/Layers | Yes | Yes |
| Split | - | - | |
| Duo | Yes | Yes | |
| Preset | Number of Preset Songs | 10 voice demo songs + 50 classics + 303 lesson songs | 10 voice demo songs + 50 classics + 303 lesson songs |
| Recording | Number of Songs | 1 | 1 |
| Number of Tracks | 2 | 2 | |
| Data Capacity | Approx. 150 KB/Song (approx. 11,000 notes) | Approx. 100 KB/Song (approx. 11,000 notes) | |
| Compatible Data Format | Playback | SMF (Format 0, Format 1) | SMF (Format 0, Format 1) |
| Recording | SMF (Format 0) | SMF (Format 0) | |
| Piano Room | - | - | |
| Overall Controls | Metronome | Yes | Yes |
| Tempo Range | 5 – 280 | 5 – 280 | |
| Transpose | -6 – 0 – +6 | -6 – 0 – +6 | |
| Tuning | 414.8 - 440.0 - 466.8 Hz (approx. 0.2 Hz increments) | 414.8 - 440.0 - 466.8 Hz (approx. 0.2 Hz increments) | |
| Scale Type | - | - | |
| Other Control | - | - | |
| Rhythm | - | - | |
| Miscellaneous | Dual/Layers | - | - |
| Duo | - | - | |
| Metronome | - | - | |
| Tempo Range | - | - | |
| Transpose | - | - | |
| Tuning | - | - | |
| Storage | Internal Memory | - | - |
| External Drives | - | - | |
| Connectivity | Headphones | Standard stereo phone jack (x 2) | Standard stereo phone jack (x 2) |
| MIDI | - | - | |
| AUX IN | - | - | |
| AUX OUT | - | - | |
| USB TO DEVICE | - | - | |
| USB TO HOST | Yes | Yes | |
| DC IN | 16 V | 12 V | |
| Amplifiers | 20 W x 2 | 8 W x 2 | |
| Speakers | 12 cm x 2 | 12 cm x 2 | |
| Acoustic Optimizer | - | - | |
| Power Consumption | 13 W (When using PA-300C AC adaptor) | 9 W (When using PA-150 AC adaptor) | |
| Auto Power Off | Yes | Yes | |
| Power Supply | Adaptors | PA-300C | PA-150 or an equivalent recommended by Yamaha |
| Accessories | Owner's Manual, 50 Classical Music Masterpieces Music Book, Online Member Product Registration, Warranty*, Bench*, Power cord*/AC adaptor* PA-300C *varies by area | Owner's Manual, 50 Classical Music Masterpieces Music Book, Online Member Product Registration, Warranty*, Power cord*/AC adaptor* PA-150 or an equivalent recommended by Yamaha *varies by area | |
