The Nord Grand features a premium weighted keybed with advanced triple sensors that capture the movements of the hammers with exceptional precision, delivering the smooth and natural feel of an acoustic grand piano.

Incorporating our award-winning performance features and hands-on user interface the lightweight Nord Grand not only provides an extraordinary playing experience, but is also an elegant new approach to our stage piano series.

MAIN FEATURES

THE GRAND EXPERIENCE

The Nord Grand is our first stage piano to feature triple sensors that track the movements on the hammers rather than the keys delivering the smooth dynamic touch of an acoustic grand.

Kawai Responsive Hammer keybed with Ivory Touch

The well balanced and responsive triple sensor keybed features an advanced mechanism providing extraordinary control both when playing percussively as well as pianissimo with fluent repetitions and retriggering without lifting the key completely.  The addition of an Ivory Touch surface gives the keybed an optimal feel and authenticity.

Nord Grand Specification

GLOBAL

• OLED Display
• Seamless Transitions
• Split Point Crossfades
• 16 banks with 25 programs - 400 locations
• Organize functionality for programs
• Live Mode - 5 Live programs
• Global Transpose: +/- 6 semitones
• Program Transpose: +/- 6 semitones
• Fine-tune: +/- 50 Cents
• Kbd Touch: 3 velocity response curves
• 88-note Kawai Responsive Hammer keybed with Advanced Triple Sensors
• Split functionality with selectable split point and LED indication
• Optional Split crossfade
• Layer functionality
• Panel Lock option
• Mono Output option
• Dynamic Sustain Pedal action with the included Nord Triple Pedal
• USB-MIDI
• Free OS updates

PIANO SECTION

• 6 types - Grand, Upright, Electric Pianos, Clavinet, Digital and Misc.
• Each category can contain up to 20 different models.
• 120 Voice Polyphony (stereo/mono pianos)
• Piano Timbre/EQ settings (Soft, Mid, Bright) with dedicated Electric Piano filters (Soft, Mid, Bright, Dyno 1 and Dyno 2).
• Advanced String Resonance (Generation 2) - adjustable amount
• Selectable Soft Release for Grand, Upright, Electric Pianos and Harpsichord
• Selectable Pedal Noise for Grand, Upright and Electric Pianos 1 - adjustable amount
• Octave transpose: -1/+1 (-6/+6 in Split mode, depending on Split position)

SAMPLE SYNTH SECTION

• 46 Voice Polyphony
• Amp envelope with Attack and Decay/Release
• Selectable velocity sensitive low pass filter and dynamic range
• Octave transpose: -1/+1 (-6/+6 in Split mode, depending on Split position)
• Volume controllable with Volume Pedal (not included)

MEMORY

• Approx. 2 GB dedicated to the Nord Piano Library
• Approx. 512 MB dedicated to the Nord Sample Library 3.0

EFFECTS SECTION

Effect 1

• Pan, Tremolo, Wah and Ring Modulator
• Three selectable depths for the Pan and Tremolo, rate controlled with the Effect 1 Rate knob
• Tremolo, Pan, Ring-Mod and Wah can be controlled with Control Pedal

Effect 2

• Phaser 1, Phaser 2, Flanger, Chorus 1, Chorus 2 and Vibe
• Two selectable depths for each effect

Amp Simulations, Comp and EQ

• Comp/Amp - three amp/speaker simulations, Tube Overdrive
• Drive/Compression amount controlled with the Drive knob
• Three band EQ, with sweepable mid. +/- 15 dB gain/attenuation

Master Effects

• Dedicated Reverb with Room, Stage and Hall algorithms, each with an additional Bright mode
• Dedicated Delay Effect - Rate, Amount and Tap-tempo function

CONNECTIONS

• 2 Audio outputs L & R - ¼", 6,35 mm jacks, unbalanced
• 1 Monitor input - 1/8", 3,5 mm stereo jack
• 1 Headphone output - ¼", 6,35 mm stereo jack
• 1 Sustain Pedal input - ¼", 6,35 mm jack. Use the included Nord Triple Pedal or a momentary pedal.
• 1 Volume Pedal input - ¼", 6,35 mm TRS stereo jack. Use a Control/Expression pedal like e.g. Yamaha FC-7, Roland EV-5 etc.
• MIDI In, MIDI Out - 5 pin DIN connectors
• USB - type B connector - for transferring sounds and USB MIDI
• IEC C14 power connector

DIMENSIONS

• Nord Grand: 1286 mm (50.7"), 168 mm (6.6"), 387 mm (15,2")
• Nord Triple Pedal: 264 mm (10.4"), 224 mm (8.8"), 70 mm (2.8")

WEIGHT

• Nord Grand: 20,9 kg (46.0 lbs)
• Pedal: 2 kg (4.4 lbs)

INCLUDED ACCESSORIES

• Nord Triple Pedal
• User Manual
• Power cord
