TC-Helicon VoiceLive Touch 2 Vocal Effects Processor

TC-Helicon VoiceLive Touch 2 Vocal Effects Processor

VOICELIVE TOUCH 2 delivers unprecedented creative control of your live sound, with state-of-the-art vocal effects and performance looping in an intuitive touch layout. You’re free to explore effects and tonal colors seamlessly while you sing - with real-time Slider FXTM providing a unique way to rock, flutter and transform your sonic landscape.

Slide Your FX

With a swipe of your finger on the Slider Bar, you can create truly unique FX riffs. We’re talking about real-time, fluid manipulation of your sound. From a subtle filter to a crazy stutter, you can modulate, intensify or pitch-sweep effects – it also works on one or all of your loops.

Easy-to-Use Interface

We’ve designed VOICELIVE TOUCH 2 for artists who need it work - immediately. Just connect it between your mic and mixer, go to your favorite preset, and start singing. Oh, and press the HIT button to see what happens...

Highlights

• Powerful mic stand-mount vocal effects processor including 4-voice harmony, touch matrix and multi-track looper

• Quickly create pro studio quality vocals with a complete suite of production-caliber vocal effects

• Adds up to 4 voices of realistic vocal harmony guided by onboard RoomSense mic or guitar / MIDI through NaturalPlay

• Adaptive Tone for perfect EQ, compression, de-essing and gating

• Touch Matrix interface with Slider FX for real-time control and modulation

• 6 track VLOOP performance looper with exciting loop-specific effects and MIDI sync

• Mic-stand mount and desktop form factor in 1 device

• USB for streaming audio, preset downloads and firmware updates

• TRS, XLR and headphone outputs

• Compatible with remote Mic Control using TC Helicon MP-75 or MP-76 microphones

• Optional SWITCH-3 or SWITCH-6 foot switch for extended performance control

• Power supply included

• 3-Year Warranty Program*

• Designed and engineered in Canada

Specifications

Effects

• uMod
• Echo & Delay
• Reverb
• Harmony
• Double
• Choir
• Transducer
• Rhythm
• Tone
• HardTune & Correction
• Guitar FX and Tuner
• VLOOP

General

• 300 customizable presets; 200 pre-programmed factory presets, 100 blank
• 9 instant-access Favorite presets
• 22 touch buttons
• Touch slider
• Simple, style based, essentials-only editing with graphics
• Genre feature to assist preset browsing
• Mic input level

Analog Inputs

• Connectors, balanced: Mic.: XLR, Guitar: 1/4³ phone jack, Aux: 1/8³ stereo mini jack
• Impedance: Balanced/Unbalanced: Mic.: 2.14/1.07 kOhm
• Mic Input Level @ 0 dBFS: -42dBu to +1dBu
• EIN @ Max Mic Gain Rg = 150 Ohm : -127 dBu
• Mic SNR: > 101 dB
• Guitar Input impedance: 1 MOhm
• Guitar Input Level @ 0 dBFS: -7 dBU to 17 dBu
• Guitar Input SNR: >115dB
• Aux Input Level @ 0dBu: +2dBu
• A to D Conversion: 24 bit, 128 x oversampling bitstream, 110dB SNR A-weighted

Analog Outputs

• D to A Conversion: 24 bit, 128 x oversampling bitstream, 115dB SNR A-weighted
• Connectors, balanced: XLR (for mono) and 1/4³ phone jack
• Output Impedance Balanced/ Unbalanced: 80/40 Ohm
• Output Range: Line: 14.5 dBu
• Dynamic Range: > 109 dB, 20 Hz to 20 kHz
• Frequency Response: +0/-0.3 dB, 20 Hz to 20 kHz
• Headphone Out: 1/8³ Mini stereo jack, 32 Ohm, +17 dBu max (180mW max)

Control

• USB: USB-B (control, MIDI and audio I/O)
• MIDI: In 5 Pin DIN
• Pedal: 1/4³ TRS phone jack

Size

• Height: 9 inches (230 mm)
• Width: 7 inches (180 mm)
• Depth: 4 inches (100 mm)

Weight

• Weight: 3.5 lb. (1.6 kg)

Construction

• Rubber coated bent aluminum and die-cast metal
• Acrylic touch panel
• Inner bent metal chassis
• Soft-touch end caps and level knobs
• Blue LCD graphic display

Power

• External Power Supply Mains Voltage: 100 to 240 VAC, 50 to 60 Hz (auto-select)
• Power Consumption: < 14 W

Safety

• EMC - Complies with: EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B
• Safety - certified to: IEC 65, EN 60065, UL6500 and CSA IEC 65, EN 60065, UL6500 and CSA

Operating

Requirements

• Operating Temperature: 32 F to 122 F (0 C to 50 C)
• Storage Temperature: -22 F to 167 F (-30 C to 70 C)
• Humidity: Max. 90 % non-condensing

Included

• Region specific power supply
• USB cable
• User guide
• Velcro cable wrap
• 1 year warranty parts and labor

Condition:Very good. Light wear typical of a gently used instrument. Light surface scratches, scuffs, etc.

The instrument pictured is the exact instrument you’ll receive. All fretted instruments receive a free complimentary professional setup.

Please feel free to reach out to our knowledgeable sales staff with any additional questions!
